ISC Class 12 Physics Syllabus 2023-24

CISCE has released the Latest Updated Syllabus of the New Academic Session 2023-24, for class 12.

Class 12th Syllabus has been released by CISCE. It’s very important for both Teachers and Students to understand the changes and strictly follow the topics covered in each subject under each stream for Class 12th.

We have also updated Oswal Gurukul Books as per the Latest Paper Pattern prescribed by Board for each Subject Curriculum.

Students can directly access the ISC Physics Syllabus for Class 12 of the academic year 2023-24 by clicking on the link below.

PDF download links to the latest Class 12 Physics Syllabus for 2023-24 academic session

Please Click on Download Now

ISC Physics Class 12 Latest Syllabus 2023-24

  1. To enable candidates to acquire knowledge and to develop an understanding of the terms, facts, concepts, definitions, and fundamental laws, principles and processes in the field of physics.
  2. To develop the ability to apply the knowledge and understanding of physics to unfamiliar situations.
  3. To develop a scientific attitude through the study of physical sciences.
  4. To develop skills in -

(a) the practical aspects of handling apparatus, recording observations and

(b) Drawing diagrams, graphs, etc.

  1. To develop an appreciation of the contribution of physics towards scientific and technological developments and towards human happiness.
  2. To develop an interest in the world of physical sciences.

There will be two papers in the subject:

Paper I: Theory - 3 hours ... 70 marks

Paper II: Practical - 3 hours ... 15 marks

Project Work ... 10 marks

Practical File ... 5 marks

S.No Unit Topic Sub-Topic Marks
1 Electrostatics

(i) Electric Charges and Fields

 Electric charges; conservation and quantisation of charge, Coulomb's law; superposition principle and continuous charge distribution. Electric field, electric field due to a point charge, electric field lines, electric dipole, electric field due to a dipole, torque on a dipole in uniform electric field.
Electric flux, Gauss’s theorem in Electrostatics and its applications to find field due to infinitely long straight wire, uniformly charged infinite plane sheet and uniformly charged thin spherical shell.

(a) Coulomb's law, S.I. unit of charge; permittivity of free space and of deielectric medium. Frictional electricity, electric charges (two types); repulsion and attraction; simple atomic structure -electrons and ions; conductors and insulators; quantization and conservation of electric charge; Coulomb's law in vector from; (position coordinates r1, r2 not necessary). Comparison with Newton's law of gravitation; Superposition principle $$(\vec{F}_1=\vec{F}_{12}+\vec{F}_{13}+\vec{F}_{14}+...).$$

 (b) Concept of electric field and its intensity; examples of different fields; gravitstional, electric and magnetic; Electric field due to a point charge $$\vec{E}=\vec{F}/q_0 $$ (q0 is a test charge); $$\vec{E}$$ for a group of charges (superposition principle); a point charge q in an electric field

$$\vec{E}$$ experiences an electric force $$\vec{F}_E=q\vec{E}$$. Intensity due to a continuous distribution of charge i.e. linear, surface and volume.

(c) Electric lines of force; A conventent way to visualize the electric field; properties of lines of force; examples of the lines of force due to (i) an isolated point charge (+ve and -ve); (ii) dipole, (ii) two similar charges of a small distance;(iv) uniform field between two oppositely charged parallel plates.

 (d) Electric dipole and dipole moment; derivation of the $$\vec{E}$$ at a point, (1) on the perpendicular bisector (equatorial i.e. broad side on position) of a dipole , also for r >> 21 (short dipole); dipole in a uniform electric field; net force zero, torque on an electric dipole: $$\vec\tau=\vec p×\vec E$$ and its derivation.

(e) Gauss' theorem: the flux of a vector field; Q=vA for velocity vector $$\vec v||\vec A.\\\vec{A}\space is \space area \space vector.\space\text{Similarly, for electric field}\space\vec{E},\\ \text{electric flux}\space\phi_E=\text{EA}\space\text{for} \vec{E}||\vec{A}\space\text{and }\phi_E=\vec{E}.\vec{A}\text{for uniform}\space\vec{E}.\\\text{For non-uniform field}\space\phi_E=\int d\phi=\int \vec{E}.d\vec{A}.\\\text{Special cases for}\space\theta=0\degree, 90\degree \text{and} 180\degree.\text{Gauss' theorem,} statement:\\\phi_E =q/\epsilon_0 \space or\space\phi_E\oint\vec{dA}=\frac{q}{\epsilon_0}\text{where}\space\phi_E\space\text{is for}$$
(ii) Electrostatic Potential, Potential Energy and Capacitance Electric potential, potential difference, electric potential due to a point charge, a dipole and system of charges; equipotential surfaces, electrical potential energy of a system of two point charges and of electric dipole in an electrostatic field. Conductors and insulators, free charges and bound charges inside a conductor. Dielectrics and electric polarisation, capacitors and capacitance, combination of capacitors in series and in parallel. Capacitance of a parallel plate capacitor, energy stored in a capacitor.

(a) Concept of potential, potential difference and potential energy. Equipotential surface and its properties. Obtain an expression for electric potential at a point due to a point charge; graphical variation of E and V vs r, Vp=W/q0; hence VA-VB= WBA/q0 (taking q0 from B to A) = (q=4πε0)(1/rA-1/rB); derive this equation; also VA=q/4πε0.1/rA; for q>0, VA>0 and for q <0, VA < 0. For a collection of charges V = algebraic sum of the potentials due to each charge;
potential due to a dipole on its axial line and equatorial line; also at any point for r > >2l (short dipole). Potential energy of a point charge (q) in an electric field$$\vec E$$, placed at a point P where potential is V, is given by U=qV and ΔU=q(VA-VB).
The electrostatic potential energy of a system of two charges = work done W21=W21 in assembling the system; U12 or U21= (1/4πε0) q1q2/r12. For a system of 3 charges U123=U12+U13+ U23 $$=\frac{1}{4\pi\epsilon_0}(\frac{q_1q_2}{r_{12}}+\frac{q_1q_3}{r_{13}}+\frac{q_2q_3}{r_{23}}).$$ For a dipole in a uniform electric field , derive an expression of the electric potential energy $$\text{U}_{E}=-\vec{P}.\vec{E},$$ special cases for Φ=0°, 90°, 180°

(b) Capacitance of a conductor C= Q/V; obtain the capacitance of a parallel-plate capacitor (C= ∈0A/d) and equivalent capacitance for capacitors in series and parallel combinations. Obtain an $$\text{expression for energy stored}\\(U=\frac{1}{2}CV^{2}=\frac{1}{2}\text{QV}=\frac{1}{2}\frac{Q^{2}}{C})\\\text{and energy density.}$$

(c) Dielectric constant K= C'/C; this is also called relative permittivity K= ∈r= ∈/∈0 ; elementory ideas of polarization of matter in a uniform electric field qualitative discussion; induced surface charges weaken the original field; results in reduction in $$\vec{E}$$ and hence, in pd, (V); for charge remaining the same Q = CV = C'V'= K. CV'; V' = V/K; and $$E'=\frac{\text{E}}{K};$$ if the Capacitor is kept connected with the source of emf, V is kept constant V = Q/C = Q'/C' ; Q'=C'V = K. CV= K. Q increases; For a parallel plate capacitor with a dielectric in between, C' = KC = K.∈o . A/d = ∈r .∈o .A/d.
$$ \text{Then}\space C'=\frac{∈_0A}{\frac{d}{∈_r}};$$ for a capacitor partially filled dielectric, capacitance, C' =∈oA/(d-t + t/∈r).

2 Current Electricity Mechanism of flow of current in conductors. Mobility, drift velocity and its relation with electric current; Ohm's law and its proof, resistance and resistivity and their relation to drift velocity of electrons; V-I characteristics (linear and non-linear), electrical energy and power, electrical resistivity and conductivity. Carbon resistors, colour code for carbon resistors; series and parallel combinations of resistors; Temperature dependence of resistance and resistivity. Internal resistance of a cell, potential difference and emf of a cell, combination of cells in series and in parallel, Kirchhoff's laws and simple applications, Wheatstone bridge, metre bridge. Potentiometer - principle and its applications to measure potential difference, to compare emf of two cells; to measure internal resistance of a cell.

(a) Free electron theory of conduction; acceleration of free electrons, relaxation time τ ; electric current I = Q/t; concept of drift velocity and electron mobility. Ohm's law, current density J = I/A; experimental verification, graphs and slope, ohmic and non-ohmic conductors; obtain the relation I=vdenA. Derive σ = ne2 τ/m and ρ = m/ne2 τ ; effect of temperature on resistivity and resistance of conductors and semiconductors and graphs. Resistance R= V/I; resistivity ρ, given by R = ρ.l/A; conductivity and conductance; Ohm’s law as $$\vec{J}=\sigma\vec{E}; $$ colour coding of resistance.

(b) Electrical energy consumed in time t is E=Pt= VIt; using Ohm’s law $$\text{E}=\bigg(\frac{V^{2}}{R}\bigg)t= I^{2}\text{Rt}.$$ Potential difference V = P/ I; P = V I; Electric power consumed P = VI = V2 /R = I2 R; commercial units; electricity consumption and billing. Derivation of equivalent resistance for combination of resistors in series and parallel; special case of n identical resistors; Rs = nR and Rp = R/n. Calculation of equivalent resistance of mixed grouping of resistors (circuits).

(c) The source of energy of a seat of emf (such as a cell) may be electrical, mechanical, thermal or radiant energy. The emf of a source is defined as the work done per unit charge to force them to go to the higher point of potential (from -ve terminal to +ve terminal inside the cell) so, ε = dW /dq; but dq = Idt; dW = εdq = εIdt . Equating total work done to the work done across the external resistor R plus the work done across the internal resistance r; εIdt=I2 R dt + I2 rdt; ε =I (R + r); I=ε/( R + r ); also IR +Ir = ε or V=ε- Ir where Ir is called the back emf as it acts against the emf ε; V is the terminal pd. Derivation of formulae for combination for identical cells in series, parallel and mixed grouping. Parallel combination of two cells of unequal emf. Series combination of n cells of unequal emf

(d) Statement and explanation of Kirchhoff's laws with simple examples. The first is a conservation law for charge and the 2nd is law of conservation of energy. Note change in potential across a resistor ∆V=IR<0 when we go ‘down’ with the current (compare with flow of water down a river), and ∆V=IR>0 if we go up against the current across the resistor. When we go through a cell, the -ve terminal is at a lower level and the +ve terminal at a higher level, so going from -ve to +ve through the cell, we are going up and ∆V=+ε and going from +ve to -ve terminal through the cell, we are going down, so ∆V = -ε. Application to simple circuits. Wheatstone bridge; right in the beginning take Ig=0 as we consider a balanced bridge, derivation of R1/R2 = R3/R4 [Kirchhoff’s law not necessary]. Metre bridge is a modified form of Wheatstone bridge, its use to measure unknown resistance. Here R3 = l1ρ and R4=l2ρ; R3R4=l1/l2. Principle of Potentiometer: fall in potential ∆V α ∆l; auxiliary emf ε1 is balanced against the fall in potential V1 across length l1. ε1 = V1 =Kl1 ; ε12 = l1/l2; potentiometer as a voltmeter. Potential gradient and sensitivity of potentiometer. Use of potentiometer: to compare emfs of two cells, to determine internal resistance of a cell.

3 Magnetic Effects of Current and Magnetism (i) Moving charges and magnetism
Concept of magnetic field, Oersted's experiment. Biot - Savart law and its application. Ampere's Circuital law and its applications to infinitely long straight wire, straight solenoid (only qualitative treatment). Force on a moving charge in uniform magnetic and electric fields. Force on a current-carrying conductor in a uniform magnetic field, force between two parallel current-carrying conductors-definition of ampere, torque experienced by a current loop in uniform magnetic field; moving coil galvanometer - its sensitivity. Conversion of galvanometer into an ammeter and a voltmeter.
(ii) Magnetism and Matter
A current loop as a magnetic dipole, its magnetic dipole moment, magnetic dipole moment of a revolving electron, magnetic field intensity due to a magnetic dipole (bar magnet) on the axial line and equatorial line, torque on a magnetic dipole (bar magnet) in a uniform magnetic field; bar magnet as an equivalent solenoid, magnetic field lines; earth's magnetic field and magnetic elements.Diamagnetic, paramagnetic, and ferromagnetic substances, with examples. Electromagnets and factors affecting their strengths, permanent magnets.

(a) Only historical introduction through Oersted’s experiment. [Ampere’s swimming rule not included]. Biot-Savart law and its vector form; application; derive the expression for B (i) at the centre of a circular loop carrying current; (ii) at any point on its axis. Current carrying loop as a magnetic dipole. Ampere’s Circuital law: statement and brief explanation. Apply it to obtain $$\vec{B}$$near a long wire carrying current and for a solenoid (straight as well as torroidal). Only formula of $$\vec{B}$$ due to a finitely long conductor.

(b) Force on a moving charged particle in magnetic field $$\vec{F}_B=q(\vec{v}×\vec{B});$$ special cases, modify this equation substituting $$\frac{d\vec{l}}{dt}\space\text{for v and I for q/dt to yield}\space\vec{F}=Id\vec{B}$$ for the force acting on a current carrying conductor placed in a magnetic field. Derive the expression for force between two long and parallel wires carrying current, hence, define ampere (the base SI unit of current) and hence, coulomb; from Q = It. Lorentz force, Simple ideas about principle, working, and limitations of a cyclotron

(c) Derive the expression for torque on a current carrying loop placed in a $$\text{uniform}\space\vec{B}, \text{ using}\space\vec{F}=I\vec{l}×\vec{B}\text{and}\space\vec\tau=\vec r×\vec F;\tau=\text{NIAB sinφ for N turns}\\\vec{\tau} =\vec{m}×\vec{B},\text{where the dipole moment}\\\vec{m}=\text{NI}\vec{A},$$ unit: A.m2 . A current carrying loop is a magnetic dipole; directions of current and $$\vec{B} \text{and}\space\vec{m}$$ using right hand rule only; no other rule necessary. Mention orbital magnetic moment of an electron in Bohr model of H atom. Concept of radial magnetic field. Moving coil galvanometer; construction, principle, working, theory I= kφ , current and voltage sensitivity. Shunt. Conversion of galvanometer into ammeter and voltmeter of given range

(d) Magnetic field represented by the symbol $$\vec{B}\space\text{is now defined by the equation}$$ $$\vec{F}=q_0(\vec{v}×\vec{B});\vec{B}\space\\\text{is not to be defined in terms of force acting on a unit pole, etc.; note the distinction of}\\ \vec{B}\space\text{from} \vec{E}\text{is that}\space\vec{B}\text{forms closed loops as there are no magnetic monopoles, whereas }\\ \vec{E} \text{lines start from +ve charge and end on -ve charge. Magnetic field lines due to a magnetic dipole (bar magnet).}\\\text{ Magnetic field in end-on and broadside-on positions (No derivations). Magnetic flux }\\\phi=\vec{B}\vec{A}=\text{BA for B uniform and}\\\vec{B}||\vec{A};\text{i.e. area held perpendicular to For}\\ \phi\text{BA}(\vec{B}||\vec{A}),$$
$$\vec{B}=\phi/A\text{is the flux density [SI unit of flux is weber (Wb)]; but note} \\\text{that this is not correct as a defining equation as}\\ \vec{B}\text{is vector and φ and φ/A are scalars, unit of B is tesla (T) equal to} 10^{-4}\\ \text{gauss. For non-uniform B field, φ}=\int d\phi=\int \vec{B}.d\vec{A}.\\\text{Earth's magnetic field }=\vec{B}_E \text{is uniform over a limited arealike that of a lab; the component of this field in the horizontal direction B}_H \\\text{is the one effectively acting on a magnet suspended or pivoted horizontally. Elements of earth’s magnetic field, i.e.} \\B_H, δ and θ - \text{their definitions and relations}$$

(e) Properties of diamagnetic, paramagnetic and ferromagnetic substances; their susceptibility and relative permeability. It is better to explain the main distinction, the cause of magnetization (M) is due to magnetic dipole moment (m) of atoms, ions or molecules being 0 for dia, >0 but very small for para and > 0 and large for ferromagnetic materials; few examples; placed in external $$\vec{B}\space\text{, very small (induced) magnetization in a direction opposite to}\\\vec{B}\space\text{in dia, small magnetization parallel to}\\\vec{B}\space\text{for para, and large magnetization parallel to}\\\vec{B}\space\text{for ferromagnetic materials; this leads to lines of}\space\vec{B}$$ becoming less dense, more dense and much more dense in dia, para and ferro, respectively; hence, a weak repulsion for dia, weak attraction for para and strong attraction for ferro magnetic material. Also, a small bar suspended in the horizontal plane becomes perpendicular to the $$\vec{B}\space\text{field for dia and parallel to} \vec{B}$$ for para and ferro. Defining equation H = (B/µ0)-M; the magnetic properties, susceptibility χm = (M/H) < 0 for dia (as M is opposite H) and > 0 for para, both very small, but very large for ferro; hence relative permeability µr =(1+ χm) < 1 for dia, > 1 for para and >>1 (very large) for ferro; further, χm∝1/T (Curie’s law) for para, independent of temperature (T) for dia and depends on T in a complicated manner for ferro; on heating ferro becomes para at Curie temperature. Electromagnet: its definition, properties and factors affecting the strength of electromagnet; selection of magnetic material for temporary and permanent magnets and core of the transformer on the basis of retentivity and coercive force (B-H loop and its significance, retentivity and coercive force not to be evaluated).

4 Electromagnetic Induction and Alternating Currents

(i) Electromagnetic Induction

Faraday's laws, induced emf and current; Lenz's Law, eddy currents. Self-induction and mutual induction. Transformer.

(ii) Alternating Current

Peak value, mean value and RMS value of alternating current/voltage; their relation in sinusoidal case; reactance and impedance;

(a) Electromagnetic induction, Magnetic flux, change in flux, rate of change of flux and induced emf; Faraday’s laws. Lenz's law, conservation of energy; motional emf ε = Blv, and power P = (Blv) 2/R; eddy currents (qualitative);

(b) Self-Induction, coefficient of selfinductance, $$\phi=\text{LI and L}=\frac{\epsilon}{\frac{dl}{dt}};$$ henry = volt. Second/ampere, expression for coefficient of self-inductance of a solenoid $$\text{L}=\frac{\mu_0N^{2}A}{l}=\mu_0n^{2} A×l.$$ Mutual induction and mutual inductance (M), flux linked φ2 = MI1; induced emf $$\epsilon_2=\frac{d\phi_2}{dt}=M\frac{dI_1}{dt}.\text{Definition of M as }\\\text{M}=\frac{\epsilon_2}{\frac{dI_1}{dt}}\text{or M}=\frac{\phi_2}{I_1}.\\ \text{SI unit henry. Expression for coefficient of mutual inductance of two coaxial solenoids.}\\ \text{M}=\frac{\mu_0N_1N_2A}{l}=\mu_0n_1N_2A$$ Induced emf opposes changes, back emf is set up, eddy currents. Transformer (ideal coupling): principle, working and uses; step up and step down; efficiency and applications including transmission of power, energy losses and their minimisation.

 (c) Sinusoidal variation of V and I with time, for the output from an ac generator; time period, frequency and phase changes; obtain mean values of current and voltage, obtain relation between RMS value of V and I with peak values in sinusoidal cases only.

(d) Variation of voltage and current in a.c. circuits consisting of only a resistor, only an inductor and only a capacitor (phasor representation), phase lag and phase lead. May apply Kirchhoff’s law and obtain simple differential equation (SHM type), V = Vo sin ωt, solution I = I0 sin ωt, I0sin (ωt + π/2) and I0 sin (ωt - π/2) for pure R, C and L circuits respectively. Draw phase (or phasor) diagrams showing voltage and current and phase lag or lead, also showing resistance R, inductive reactance XL; (XL=ωL) and capacitive reactance XC, (XC = 1/ωC). Graph of XL and XC vs f

(e) The LCR series circuit: Use phasor diagram method to obtain expression for I and V, the pd across R, L and C; and the net phase lag/lead; use the results of 4(e), V lags I by π/2 in a capacitor, V leads I by π/2 in an inductor, V and I are in phase in a resistor, I is the same in all three; hence draw phase diagram, combine VL and Vc (in opposite phase; phasors add like vectors) to give V=VR+VL+VC (phasor addition) and the max. values are related by V2 m=V2 Rm+(VLm-VCm)2 when VL>VC Substituting pd=current x resistance or reactance, we get Z2 =R2 +(XL-Xc) 2 and tanφ = (VL m -VCm)/VRm = (XL-Xc)/R giving I = I m sin (wt-φ) where I m =Vm/Z etc. Special cases for RL and RC circuits. [May use Kirchoff’s law and obtain the differential equation] Graph of Z vs f and I vs f

(f) Power P associated with LCR circuit = $$\frac{1}{2}V_0I_0\text{cos}\phi= V_{rms}I_{rms}\space\text{cos} \phi=I rms^{2} R;\\\text{power absorbed and power dissipated; electrical resonance; bandwidth of signals}\\\text{ and Q factor (no derivation); oscillations in an LC circuit}(\omega_0=\frac{1}{\sqrt{LC}})\\\text{Average power consumed averaged over a full cycle}\\\bar{P}=(1/2)\space V_0I_0\space cos\phi,$$ Power factor cosφ = R/Z. Special case for pure R, L and C; choke coil (analytical only), XL controls current but cosφ = 0, hence $$\bar{P}=0 \text{wattless current; LC circuit; at resonance with} X_L=X_c , Z=Z_{min}= R,\\\text{ power delivered to circuit by the source is maximum, resonant frequency}\\f_0=\frac{1}{2\pi\sqrt{LC}}.$$

(g) Simple a.c. generators: Principle, description, theory, working and use. Variation in current and voltage with time for a.c. and d.c. Basic differences between a.c. and d.c.

5 Electromagnetic Waves Basic idea of displacement current. Electromagnetic waves, their characteristics, their transverse nature (qualitative ideas only). Complete electromagnetic spectrum starting from radio waves to gamma rays: elementary facts of electromagnetic waves and their uses. Concept of displacement current, qualitative descriptions only of electromagnetic spectrum; common features of all regions of electromagnetic spectrum including transverse nature ( $$\vec{E}\space\text{and}\space\vec{B}\space\text{perpendicular to}\space\vec{c}$$); special features of the common classification (gamma rays, X rays, UV rays, visible light, IR, microwaves, radio and TV waves) in their production (source), detection and other properties; uses; approximate range of λ.
6 Optics

(i) Ray Optics and Optical Instruments

Ray Optics: Reflection of light by spherical mirrors, mirror formula, refraction of light at plane surfaces, total internal reflection and its applications, optical fibres, refraction at spherical surfaces, lenses, thin lens formula, lens maker's formula, magnification, power of a lens, combination of thin lenses in contact, combination of a lens and a mirror, refraction and dispersion of light through a prism. Scattering of light.

Optical instruments: Microscopes and astronomical telescopes (reflecting and refracting) and their magnifying powers and their resolving powers.

(a) Reflection of light by spherical mirrors. Mirror formula: its derivation; R=2f for spherical mirrors. Magnification.

(b) Refraction of light at a plane interface, Snell's law; total internal reflection and critical angle; total reflecting prisms and optical fibers. Total reflecting prisms: application to triangular prisms with angle of the prism 30° , 45° , 60° and 90° respectively; ray diagrams for Refraction through a combination of media, 1n2× 2n3× 3n1=1, real depth and apparent depth. Simple applications

(c) Refraction through a prism, minimum deviation and derivation of relation between n, A and δmin. Include explanation of i-δ graph, i1 = i2 = i (say) for δm; from symmetry r1 = r2; refracted ray inside the prism is parallel to the base of the equilateral prism. Thin prism. Dispersion; Angular dispersion; dispersive power, rainbow - ray diagram (no derivation). Simple explanation. Rayleigh’s theory of scattering of light: blue colour of sky and reddish appearance of the sun at sunrise and sunset clouds appear white.

(d) Refraction at a single spherical surface; detailed discussion of one case only - convex towards rarer medium, for spherical surface and real image. Derive the relation between n1, n2, u, v and R. Refraction through thin lenses: derive lens maker's formula and lens formula; derivation of combined focal length of two thin lenses in contact. Combination of lenses and mirrors (silvering of lens excluded) and magnification for lens, derivation for biconvex lens only; extend the results to biconcave lens, plano convex lens and lens immersed in a liquid; power of a lens P=1/f with SI unit dioptre. For lenses in contact 1/F= 1/f1+1/f2 and P=P1+P2. Lens formula, formation of image with combination of thin lenses and mirrors.
[Any one sign convention may be used in solving numericals].

(e) Ray diagram and derivation of magnifying power of a simple microscope with image at D (least distance of distinct vision) and infinity; Ray diagram and derivation of magnifying power of a compound microscope with image at D. Only expression for magnifying power of compound microscope for final image at infinity.
Ray diagrams of refracting telescope with image at infinity as well as at D; simple explanation; derivation of magnifying power; Ray diagram of reflecting telescope with image at infinity. Advantages, disadvantages and uses. Resolving power of compound microscope and telescope.


(ii) Wave Optics

Wave front and Huygen's principle. Proof of laws of reflection and refraction using Huygen's principle. Interference, Young's double slit experiment and expression for fringe width(β), coherent sources and sustained interference of light, Fraunhofer diffraction due to a single slit, width of central maximum, polarisation, plane polarised light, Brewster's law, uses of plane polarised light and Polaroids.

(a) Huygen’s principle: wavefronts - different types/shapes of wavefronts; proof of laws of reflection and refraction using Huygen’s theory. [Refraction through a prism and lens on the basis of Huygen’s theory not required].

(b) Interference of light, interference of monochromatic light by double slit. Phase of wave motion; superposition of identical waves at a point, path difference and phase difference; coherent and incoherent sources; interference: constructive and destructive, conditions for sustained interference of light waves [mathematical deduction of interference from the equations of two progressive waves with a phase difference is not required]. Young's double slit experiment: set up, diagram, geometrical deduction of path difference ∆x = dsinθ, between waves from the two slits; using ∆x=nλ for bright fringe and ∆x= (n+½)λ for dark fringe and sin θ = tan θ =yn /D as y and θ are small, obtain yn=(D/d)nλ and fringe width β=(D/d)λ. Graph of distribution of intensity with angular distance.

(c) Single slit Fraunhofer diffraction (elementary explanation only). Diffraction at a single slit: experimental setup, diagram, diffraction pattern, obtain expression for position of minima, a sinθn= nλ, where n = 1,2,3… and conditions for secondary maxima, asinθn =(n+½)λ.; distribution of intensity with angular distance; angular width of central bright fringe.

(d) Polarisation of light, plane polarised electromagnetic wave (elementary idea only), methods of polarisation of light. Brewster's law; polaroids. Description of an electromagnetic wave as transmission of energy by periodic changes in $$\vec{E}\space\text{and}\space\vec{B}\space\text{along the path; transverse nature as}\\\vec{E}\space\text{and}\space\vec{B}\text{are perpendicular to}\space\vec{c}$$ These three vectors form a right handed system, so that $$\vec{E}×\vec{B}\space\text{is along}\vec{c}$$, they are mutually perpendicular to each other. For ordinary light, $$\vec{E} \text{and} \vec{B}\space\text{are in all directions in a plane perpendicular to the}\\\space\vec{c}\space\text{vector - unpolarised waves.}$$ $$\text{If}\space\vec{E}\space\text{and (hence} \vec{B}\space\text{also ) is confined to a single plane only} $$ $$(\perp \vec{c}, \text{we have linearly polarized light. The plane containing} \vec{E} (or \vec{B}) and\space\vec{c} remains fixed.\\\text{ Hence, a linearly polarised light is also called plane polarised light. Plane of polarisation (contains )} \vec{E} and \vec{c};$$ polarisation by reflection; Brewster’s law: tan ip=n; refracted ray is perpendicular to reflected ray for i= ip; ip+rp = 90° ; polaroids; use in the production and detection/analysis of polarised light, other uses. Law of Malus.

7 Dual Nature of Radiation and Matter Wave particle duality; photoelectric effect, Hertz and Lenard's observations; Einstein's photoelectric equation - particle nature of light. Matter waves - wave nature of particles, de-Broglie relation , conclusion from Davisson-Germer experiment. X-rays. s

(a) Photo electric effect, quantization of radiation; Einstein's equation Emax = hυ - W0; threshold frequency; work function; experimental facts of Hertz and Lenard and their conclusions; Einstein used Planck’s ideas and extended it to apply for radiation (light); photoelectric effect can be explained only assuming quantum (particle) nature of radiation. Determination of Planck’s constant (from the graph of stopping potential Vs versus frequency f of the incident light). Momentum of photon p=E/c=hν/c=h/λ.

(b) De Broglie hypothesis, phenomenon of electron diffraction (qualitative only). Wave nature of radiation is exhibited in interference, diffraction and polarisation; particle nature is exhibited in photoelectric effect. Dual nature of matter: particle nature common in that it possesses momentum p and kinetic energy KE. The wave nature of matter was proposed by Louis de Broglie, λ=h/p= h/mv. Davisson and Germer experiment; qualitative description of the experiment and conclusion.

(c) A simple modern X-ray tube (Coolidge tube) – main parts: hot cathode, heavy element anode (target) kept cool, all enclosed in a vacuum tube; elementary theory of X-ray production; effect of increasing filament current- temperature increases rate of emission of electrons (from the cathode), rate of production of X rays and hence, intensity of X rays increases (not its frequency); increase in anode potential increases energy of each electron, each X-ray photon and hence, X-ray frequency (E=hν); maximum frequency hνmax =eV; continuous spectrum of X rays has minimum wavelength λmin= c/νmax=hc/eV. Moseley’s law. Characteristic and continuous X rays, their origin. (This topic is not to be evaluated)

8 Atoms and Nuclei (i) Atoms Rutherford’s nuclear model of atom (mathematical theory of scattering excluded), based on Geiger - Marsden experiment on α-scattering; nuclear radius r in terms of closest approach of α particle to the nucleus, obtained by equating ∆K=½ mv2 of the α particle to the change in electrostatic potential energy ∆U of the system $$[\text{U} = \frac{2e×ze}{4\pi\epsilon_0r_0}\space r_0∼ 10^{\normalsize-15}m = 1\space\text{fermi};$$ atomic structure; only general qualitative ideas, including atomic number Z, Neutron number N and mass number A. A brief account of historical background leading to Bohr’s theory of hydrogen spectrum; formulae for wavelength in Lyman, Balmer, Paschen, Brackett and Pfund series. Rydberg constant. Bohr’s model of H atom, postulates (Z=1); expressions for orbital velocity, kinetic energy, potential energy, radius of orbit and total energy of electron. Energy level diagram, calculation of ∆E, frequency and wavelength of different lines of emission spectra; agreement with experimentally observed values. [Use nm and not Å for unit of λ].
Alpha-particle scattering experiment; Rutherford's atomic model; Bohr’s atomic model, energy levels, hydrogen spectrum.

(ii) Nuclei

Composition and size of nucleus. Radioactivity, alpha, beta and gamma particles/rays and their properties; radioactive decay law. Mass-energy relation, mass defect; binding energy per nucleon and its variation with mass number; Nuclear reactions, nuclear fission and nuclear fusion.

(a) Atomic masses and nuclear density; Isotopes, Isobars and Isotones – definitions with examples of each. Unified atomic mass unit, symbol u, 1u=1/12 of the mass of 12C atom = 1.66x10-27kg). Composition of nucleus; mass defect and binding energy, BE= (∆m) c2 . Graph of BE/nucleon versus mass number A, special features - less BE/nucleon for light as well as heavy elements. Middle order more stable [see fission and fusion] Einstein’s equation E=mc2 . Calculations related to this equation; mass defect/binding energy, mutual annihilation and pair production as examples.

(b) Radioactivity: discovery; spontaneous disintegration of an atomic nucleus with the emission of α or β particles and γ radiation, unaffected by physical and chemical changes. Radioactive decay law; derivation of N = Noe-λt ; half-life period T; graph of N versus t, with T marked on the X axis. Relation between half-life (T) and disintegration constant (λ); mean life (τ) and its relation with λ. Value of T of some common radioactive elements. Examples of a few nuclear reactions with conservation of mass number and charge, concept of a neutrino.

Changes taking place within the nucleus included. [Mathematical theory of α and β decay not included].

(c) Nuclear Energy Theoretical (qualitative) prediction of exothermic (with release of energy) nuclear reaction, in fusing together two light nuclei to form a heavier nucleus and in splitting heavy nucleus to form middle order (lower mass number) nuclei, is evident from the shape of BE per nucleon versus mass number graph. Also calculate the disintegration energy Q for a heavy nucleus (A=240) with BE/A ∼ 7.6 MeV per nucleon split into two equal halves with A=120 each and BE/A ∼ 8.5 MeV/nucleon; Q ∼ 200 MeV. Nuclear fission: Any one equation of fission reaction. Chain reactioncontrolled and uncontrolled; nuclear reactor and nuclear bomb. Main parts of a nuclear reactor including their functions - fuel elements, moderator, control rods, coolant, casing; criticality; utilization of energy output - all qualitative only. Fusion, simple example of 4 $$^{1}H\xrightarrow{}^{4}\text{He}$$ and its nuclear reaction equation; requires very high temperature ∼ 106 degrees; difficult to achieve; hydrogen bomb; thermonuclear energy production in the sun and stars. [Details of chain reaction not required].

9 Electronic Devices (i) Semiconductor Electronics: Materials, Devices and Simple Circuits. Energy bands in conductors, semiconductors and insulators (qualitative ideas only). Intrinsic and extrinsic semiconductors.
(ii) Semiconductor diode: I-V characteristics in forward and reverse bias, diode as a rectifier; Special types of junction diodes: LED, photodiode, solar cell and Zener diode and its characteristics, zener diode as a voltage regulator.
(iii) Junction transistor, npn and pnp transistor, transistor action, characteristics of a transistor and transistor as an amplifier (common emitter configuration).
(iv) Elementary idea of analogue and digital signals, Logic gates (OR, AND, NOT, NAND and NOR). Combination of gates. (a) Energy bands in solids; energy band diagrams for distinction between conductors, insulators and semi-conductors - intrinsic and extrinsic; electrons and holes in semiconductors.
Elementary ideas about electrical conduction in metals [crystal structure not included].
Energy levels (as for hydrogen atom), 1s, 2s, 2p, 3s, etc. of an isolated atom such as that of copper; these split, eventually forming ‘bands’ of energy levels, as we consider solid copper made up of a large number of isolated atoms, brought together to form a lattice; definition of energy bands - groups of closely spaced energy levels separated by band gaps called forbidden bands. An idealized representation of the energy bands for a conductor, insulator and semiconductor; characteristics, differences; distinction between conductors, insulators and semiconductors on the basis of energy bands, with examples; qualitative discussion only; energy gaps (eV) in typical substances (carbon, Ge, Si); some electrical properties of semiconductors. Majority and minority charge carriers - electrons and holes; intrinsic and extrinsic, doping, p-type, n-type; donor and acceptor impurities.
(b) Junction diode and its symbol; depletion region and potential barrier; forward and reverse biasing, V-I characteristics and numericals; half wave and a full wave rectifier. Simple circuit diagrams and graphs, function of each component in the electric circuits, qualitative only. [Bridge rectifier of 4 diodes not included]; elementary ideas on solar cell, photodiode and light emitting diode (LED) as semi conducting diodes. Importance of LED’s as they save energy without causing atmospheric pollution and global warming. Zener diode, V-I characteristics, circuit diagram and working of zener diode as a voltage regulator.
(c) Junction transistor; simple qualitative description of construction - emitter, base and collector; npn and pnp type; symbols showing direction of current in emitter-base region (one arrow only)- base is narrow; current gains in a transistor, relation between α, β and numericals related to current gain, voltage gain, power gain and transconductance; common emitter configuration only, characteristics; IB vs VBE and IC vs VCE with circuit diagram and numericals; common emitter transistor amplifier - circuit diagram; qualitative explanation including amplification, wave form and phase reversal.
(d) Elementary idea of discreet and integrated circuits, analogue and digital signals. Logic gates as given; symbols, input and output, Boolean equations (Y=A+B etc.), truth table, qualitative explanation. NOT, OR, AND, NOR, NAND. Combination of gates [Realization of gates not included]. Advantages of Integrated Circuits.
10 Communication Systems Elements of a communication system (block diagram only); bandwidth of signals (speech, TV and digital data); bandwidth of transmission medium. Modes of propagation of electromagnetic waves in the atmosphere through sky and space waves, satellite communication. Modulation, types (frequency and amplitude), need for modulation and demodulation, advantages modulation over of amplitude frequency modulation. Elementary ideas about internet, mobile network and global positioning system (GPS). Self-explanatory- qualitative only.
